| 处理器 | CPU | Core I3-4200U Core I5-5200U Core i5-5287U |
| Core Number | 2 2 2 | |
| # of P-cores | ||
| # of E-cores | ||
| Thread Number | 4 4 4 | |
| Performance-core Turbo Frequency | ||
| Efficient-core Turbo Frequency | ||
| Max Turbo Frequency | 2.60 GHz 2.70 GHz 3.30 GHz | |
| Performance-core Base Frequency | ||
| Efficient-core Base Frequency | ||
| Processor Base Frequency | 1.60 GHz 2.20 GHz 2.90 GHz | |
| Socket | ||
| Chipset | ||
| NPU | ||
| Cache (MB) | Smart Cache: 3MB | |
| CPU TDP | 15W 15W 28W | |
| BIOS | ||
| 内存 | Technology | DDR3L 1333MHz |
| Max capacity | 8GB | |
| ECC Support | ||
| Socket | 1x SO-DIMM 204 Pin | |
| Internal Memory | ||
| 显示 | Controller | Intel HD Graphics (Depend on the CPU model) |
| Graphic Engine | DirectX 11.2, OpenGL4.3 | |
| H/ W Video Codec | ||
| LCD (TTL/ LVDS/ eDP) | ||
| ADI (BNC/ VGA/ DVI-I) | VGA: Up to 1920x1080@60 Hz | |
| DDI (DVI-D/ HDMI/ DP) | HDMI: Up to 3840x2160@24Hz | |
| Multiple Display | Dual | |
| 以太网控制器 | Controller | LAN 1-2: Realtek RTL8111H |
| Speed | 10/ 100/ 1000 Mbps | |
| Connector | ||
| 音频 | Audio Interface | HD Audio |
| CODEC | Realtek, High Definition Audio (HD) | |
| Amplifier | ||
| Connector | ||
| 扩展 | PCI Expressx16 | |
| PCI Expressx8 | ||
| PCI Expressx4 | ||
| PCI Expressx2 | ||
| PCI Expressx1 | ||
| PCI | ||
| Mini PCIe | Full-size: Wi-Fi | |
| M.2 Key-E | ||
| M.2 Key-B | ||
| TF card Slot | ||
| SIM Card Slot | ||
| Type-C | ||
| TPM | ||
| Bus interface | ||
| 存储 | Memory Card | |
| SATA | ||
| mSATA | Full-size: mSATA3.0 for SSD | |
| M.2 Key-B | ||
| M.2 Key-M | ||
| RAID | ||
| 输入输出 | Display | |
| USB 2.0 | ||
| USB 3.2 Gen 1 | ||
| USB 3.2 Gen 2 | ||
| USB 3.2 Gen 2×2 | ||
| Type-C | ||
| COM Port | ||
| GPIO | ||
| Digital I/ O | ||
| Bus interface | ||
| PS/ 2 | ||
| LPT | ||
| Smart Fan | ||
| TF card Slot | ||
| SIM Card Slot | ||
| Industry Connectors | ||
| 前面板 | Display | |
| RJ-45 | ||
| USB 2.0 | 6 | |
| USB 3.2 Gen 1 | ||
| USB 3.2 Gen 2 | ||
| USB 3.2 Gen 2×2 | ||
| Type-C | ||
| COM Port | 10 (9x RS-232, 1x RS-232/ 485) | |
| GPIO | ||
| Digital I/ O | ||
| Bus interface | ||
| PS/ 2 | ||
| Audio | ||
| LPT | ||
| TF card Slot | ||
| SIM Card Slot | ||
| Industry Connectors | ||
| On-board Pin Header Extension (optional) | ||
| 后置面板 | Display | VGA, HDMI |
| RJ-45 | 2 | |
| USB 2.0 | ||
| USB 3.2 Gen 1 | 2 | |
| USB 3.2 Gen 2 | ||
| USB 3.2 Gen 2×2 | ||
| Type-C | ||
| COM Port | ||
| GPIO | ||
| Digital I/ O | ||
| Bus interface | ||
| PS/ 2 | ||
| Audio | 2 (Line out, Mic-in) | |
| LPT | ||
| TF Card Slot | ||
| SIM Card Slot | ||
| Industry Connectors | ||
| On-board Pin Header Extension (optional) | ||
| 侧面板 | Display | |
| RJ-45 | ||
| USB 2.0 | ||
| USB 3.2 Gen 1 | ||
| USB 3.2 Gen 2 | ||
| USB 3.2 Gen 2×2 | ||
| Type-C | ||
| COM Port | ||
| GPIO | ||
| Digital I/ O | ||
| Bus interface | ||
| PS/ 2 | ||
| Audio | ||
| LPT | ||
| TF card Slot | ||
| SIM Card Slot | ||
| Industry Connectors | ||
| On-board Pin Header Extension (optional) | ||
| 其他 | LED Indicators | SYS |
| Control | ON/ OFF | |
| Watchdog Timer | Support | |
| 电源 | Power Type | DC |
| Connector | DC Circular plug | |
| Power Consumption (Full Load) | ||
| Input Voltage | 12V | |
| Battery | Lithium 3V/ 200 mAh | |
| 使用环境 | Operational Temperature | 0 ~ 60 °C (32 ~ 140 °F) with 0.7m/ s air flow |
| Non-Operational Temperature | -40 ~ 80 °C (-40 ~ 176 °F) | |
| Relative Humidity | 95%@40 °C (non-Condensing) | |
| 支持系统 | Microsoft Windows | 7, 10 |
| Linux | Yes (by Project) | |
| Android | ||
| BSD | ||
| 国产操作系统 | ||
| 物理规格 | Mounting | |
| Dimension(mm) | ||
| Dimension(WxHxD mm) | 234x68.8x227.5 | |
| Weight (Kg) | TBD |
